~50 %
Bagasse moisture as fired
Industries · Application engineering
Industrial dust collection by industry: the fuel decides the collector
Dust collectors are not selected by industry name but by what the industry burns. Bagasse at ~50 % moisture with heavy char carryover, rice husk ash at 85–90 % amorphous silica, cement kiln dust at high resistivity — each fuel and process writes its own particle-size distribution, ash chemistry and gas condition, and those write the collection train.
7.2–7.5 MJ/kg
Bagasse LHV
85–90 % amorphous SiO₂
Rice husk ash silica
6,000 → 24 mg/Nm³ @ 6 % O₂ dry
Design-basis bagasse train
01 — Selection logic
Industrial dust collection starts with the fuel analysis
Same boiler size, different fuel — different collector.
Two 100 t/h boilers can need entirely different gas-cleaning trains. What separates them is not the industry label but four fuel-driven properties: moisture (which sets gas volume and temperature), ash content and chemistry (which set dust loading and resistivity), particle-size distribution (which sets what each collection technology can catch), and the site's permit limit in mg/Nm³ at stated O₂. Arrow Energy Co., Ltd. works across seven solid-fuel and process industries, and the pages below apply the same selection logic to each fuel rather than repeating a catalogue seven times.
Why does the fuel decide the dust collector?
Because every collection mechanism has a fuel-shaped weakness. Bagasse char burns as embers that a bag filter cannot safely swallow but an Electrocyclone quenches at up to 400 °C. High-resistivity dust above 10¹¹ Ω·cm drives an ESP into back-corona. Wet, alkali-rich ash blinds fabric. The fuel analysis reveals which weaknesses apply — before the collector is chosen, not after.
Where a limit is tight and the raw-gas load heavy, the answer is staged collection: in the bagasse design basis, 6,000 mg/Nm³ at 6 % O₂ dry falls to 720 mg/Nm³ across an Electrocyclone and to 24 mg/Nm³ behind a four-field electrostatic precipitator. Installed examples per industry are listed, on a stated basis, in the project reference database.
02 — Comparison
Seven industries, one table
Indicative fuel properties — typical literature ranges; design always uses the project fuel analysis.
| Industry | Fuel / dust source | Moisture, % | Ash, % | Dominant challenge | Typical train |
|---|---|---|---|---|---|
| Sugar & bagasse | Bagasse (LHV 7.2–7.5 MJ/kg) | ~50 | 2–4 | Char carryover, abrasive silica-rich ash | Electrocyclone + ESP |
| Biomass power | Wood chip, mixed residues | 30–55 | 1–5 | Fuel variability, embers, high excess air | Electrocyclone + ESP, or bag filter |
| Cement | Kiln and raw-meal dust | Process gas | Dust load in g/Nm³ range | High resistivity, high inlet loading | ESP or bag filter, duty-dependent |
| Pulp & paper | Bark, hog fuel | 40–60 | 1–3 | Alkali-rich, partly sticky ash | ESP |
| Waste-to-energy | MSW / RDF | 30–45 | 15–25 | Acid gases (SO₂, HCl), corrosion | Flue-gas treatment + bag filter |
| Palm oil | Fibre, shell, EFB | 40–65 | 3–8 | Potassium fouling, wet plume | Multicyclone or Electrocyclone + ESP |
| Rice husk | Rice husk | ~10 | 15–20 (ash 85–90 % SiO₂) | Sheer ash volume, silica abrasion | Pre-collector + ESP; silica extraction |
The last column is a starting point, not a verdict — permit limit, plot space and fan margin move individual projects off the typical train. Rice husk is the one row where the ash is worth more than the disposal cost: at 85–90 % amorphous silica it feeds the silica extraction service.
03 — The industries
Application pages, fuel by fuel
Each page carries the fuel data, the train logic and the numbers that size it.
Bagasse · ~50 % moisture
Sugar & bagasse
The home application of the worked design basis: 60 t/h bagasse boiler, 6,000 → 24 mg/Nm³ across an Electrocyclone + four-field ESP train, planned around the off-crop outage.
Dust collection for sugar and bagasse plantsMixed residues
Biomass power
Variable fuel mixes, ember carryover and high excess air — collection trains and λ-trim arithmetic for independent power producers.
Dust collection for biomass power plantsg/Nm³ dust loads
Cement
Kiln, raw mill and cooler duties where resistivity and inlet loading — not fuel moisture — govern the ESP-versus-bag-filter decision.
Dust collection for cement plantsBark & hog fuel
Pulp & paper
Power-boiler gas cleaning for alkali-rich bark ash, engineered around the mill's steam and recovery cycle.
Dust collection for pulp and paper millsAcid-gas duty
Waste-to-energy
Where particulate control meets SO₂ and HCl abatement: flue-gas treatment paired with fabric filtration and corrosion-conscious design.
Emission control for waste-to-energy plantsFibre, shell, EFB
Palm oil
High-moisture fuels and potassium-fouling ash at palm oil mills — train selection that keeps the boiler and the stack both in bounds.
Dust collection for palm oil mills85–90 % silica ash
Rice husk
Fifteen to twenty percent ash by mass, nearly all amorphous silica: collection, abrasion design, and the extraction route that turns the ash into product.
Dust collection for rice husk firingFAQ
Engineering questions, answered
Why do different industries need different dust collectors?
Because the fuel sets the dust. Bagasse at ~50 % moisture produces coarse, abrasive, silica-rich fly ash with char carryover — well suited to an Electrocyclone plus ESP train reaching 24 mg/Nm³ in our design basis. Waste fuels add acid gases that demand flue-gas treatment; cement dust brings resistivity that governs ESP sizing.
Which dust collection train is typical for a sugar mill?
A two-stage train: an Electrocyclone pre-collector removing 85–95 % of the coarse abrasive load at up to 400 °C, followed by an ESP sized for the fine remainder. In the worked design basis for a 60 t/h bagasse boiler this reaches 24 mg/Nm³ at 6 % O₂ dry — 99.60 % overall — with 57 mg/Nm³ still available with one field out.
Does the same equipment work if the plant changes fuel?
Only within limits, and this is the most common cause of a compliant plant going non-compliant. Switching bagasse to wood chip or adding rice husk changes ash loading, particle size and resistivity, so a collector sized for one fuel may need added fields or a pre-collector for another. A fuel change justifies a new assessment on a measured basis.
